Description
US Stock SFX M24HR Electric Tapping Machine with ANSI Collects 1200W High Precision Reduce Broken Taps Universal Tapping High Rotary Speed
The SFX M24HR Electric Tapping Machine offers a great solution for creating threaded holes with precision and efficiency. The M24HR has a high rotary speed and can be used for M4-M20 threading on steel, aluminum, stainless steel, wood, plastic, and so on. The electric tapping arm is equipped with an intuitive user interface, ensuring ease of operation, and making it accessible to operators with varying levels of experience.
Specification:
Model: SFX-M24HR
Customized: Yes
Power Type: AC Power
Rated Power: 1200W
Supply Voltage: 110V 60HZ
Spindle Rated Speed: 0-550r/min high speed
Tapping Range (steel, stainless steel, aluminum): M4-M20 (Copper, stainless steel)
M4-M24 (Aluminum)
Working Range: Horizontal: 1180mm Vertical: 400mm adjustable
Weight: 49kg
Universal Tapping: Yes
Oiling Function: No
Lifting Function: No
Tapping Chuck configuration:
TC820 ANSI Tapping Collets (10pcs) 8,5/32″, 10,3/16″, 14,1/4″, 5/16″, 3/8″, 1/2″, 9/16″, 5/8″, 11/16″, 13/16″
Service:
US Stock, fast free shipping with door-to-door service.
After-sales service is provided.
Note: The workbench is not included, you can buy it separately.
